COMF-E® Series Performanced Laminated Glass
Categories: LAMINATED GLASS
Landson Glass is committed to supplying the global glass industries with the most innovative glazing solutions to meet the most challenging contemporary building designs. Be it to achieve exceptional energy performance or structural glazing requirements. Landson Glass will manufacture or source specific products customized for individual projects. Landson Glass offers unrivalled flexibility to meet any requirements.
Laminated safety glass offers enhanced safety by remaining intact even when broken, that the key point is to its interlayer. This minimizes the risk of injury from sharp edges, making it ideal for building windows, shower doors, and safety barriers or commericial communities.
Features
Laminated safety glass offers enhanced safety by remaining intact even when broken, that interlayer. This minimizes the risk of injury from sharp edges, making it ideal for building safety barriers or commercial communities.
Landson Glass ‘s COMF-E Series Laminated Glass is especially experienced in the Southern Hemisphere. Our collective experience and continued investment is our manufacturing capability on high performance Low-E laminated glass, mean our clients can import with confidence and peace of mind, which brings cooler, quieter, safer glass built for your home.
✅ All products meet AS/NZS 2208 safety standard
✅ Help achieve WERS ratings & NatHERS energy targets
✅ Built for harsh Australian conditions – sun, storms, heat
✅ Highly UV blockage protects your furniture and family
KEY SPECIFICATIONS
| Thickness | 6.38-33.04mm |
| Interlayers | PVB (Architectural & Acoustic), SG®,and Vanceva®,DG, SG interlayers |
| Processing Capability | Sizes up to 3210*5180mm Multi-laminated options available Silkscreen frit patterns and Digital All edgework and drilling processes (holes, cutouts) available |
| Glass types | COMF-E ULTRA(CLEAR), COMF-E COOL(Solarcontrol), COMF-E SOLAR(Neutral), COMF-E SKY, COMF-E SUNTECH，COMF-E ULTRA GREY，COMF-E ACOUSTIC |
| Standard interlayer colours: | Clear, White Translucent, Grey, Bronze, Green & Blue |
| Leadtime | 2-3 weeks ex-factory |
| Packaging | Plywood endcaps or Steel A frames, or can be made to customer’s requirements |
PERFORMANCE SPECIFICATIONS
| NO. | GLASS MAKE-UP | MM | LIGHT PROPERTIES | SOLAR ENERGY | U VALUE | SHGC | SC | |||||||
| Trans(%) | Refl Out | Refl In | Trans(%) | Rfsol | Rbsol | Abs1 | UV | In Winter | In Summer | |||||
| 1 | COMF-E® Ultra Laminate | 6.38 | 84.0 | 10.9 | 10.2 | 67.6 | 10.6 | 8.7 | 21.9 | 3.680 | 2.850 | 0.720 | 0.820 | |
| 2 | COMF-E® Ultra Laminate | 10.38 | 82.7 | 10.8 | 10.2 | 61.3 | 9.5 | 11.5 | 28.2 | 3.600 | 2.780 | 0.670 | 0.770 | |
| 3 | COMF-E® Ultra Laminate | 12.38 | 81.9 | 9.7 | 10.2 | 58.4 | 8.3 | 11.0 | 33.0 | 3.590 | 2.800 | 0.650 | 0.750 | |
| 4 | COMF-E® Ultra Laminate | 16.76 | 79.0 | 10.4 | 11.4 | 54.3 | 8.2 | 10.0 | 41.0 | 3.490 | 2.690 | 0.620 | 0.710 | |
| 5 | COMF-E® Ultra Grey Laminate | 6.38 | 42.0 | 6.0 | 9.0 | 42.0 | 7.0 | 8.0 | 51.0 | 3.690 | 2.845 | 0.517 | 0.595 | |
| 6 | COMF-E® Ultra Grey Laminate | 10.38 | 41.5 | 6.0 | 9.0 | 36.0 | 7.0 | 10.0 | 57.0 | 3.610 | 2.790 | 0.540 | 0.470 | |
| 7 | COMF-E® Ultra Grey Laminate | 12.38 | 41.0 | 6.0 | 8.0 | 35.0 | 6.0 | 10.0 | 59.0 | 3.570 | 2.770 | 0.540 | 0.470 | |
| 8 | COMF-E® Solar Laminate | 10.38 | 58.6 | 7.2 | 9.0 | 39.8 | 6.6 | 11.4 | 53.6 | 3.595 | 2.778 | 0.504 | 0.579 | |
| 9 | COMF-E® Solar Laminate | 12.38 | 58.3 | 7.7 | 9.2 | 37.8 | 6.5 | 11.5 | 55.7 | 3.562 | 2.758 | 0.489 | 0.563 | |
| 10 | COMF-E® Sky Laminate | 6.38 | 67.7 | 8.4 | 9.5 | 59.0 | 8.6 | 10.6 | 32.4 | 3.690 | 2.840 | 0.650 | 0.750 | |
| 11 | COMF-E® Sky Laminate | 10.38 | 61.5 | 7.6 | 8.9 | 53.3 | 7.6 | 10.3 | 39.1 | 3.590 | 2.760 | 0.610 | 0.700 | |
| 12 | COMF-E® Suntech Laminate | 6.38 | 57.8 | 7.7 | 9.6 | 41.4 | 9.3 | 10.6 | 49.3 | 3.710 | 2.860 | 0.510 | 0.580 | |
| 13 | COMF-E® Suntech Laminate | 10.38 | 52.3 | 7.7 | 9.2 | 34.5 | 7.9 | 10.6 | 57.6 | 3.600 | 2.770 | 0.460 | 0.530 | |
| Note:
1. The above Landson Glass’ performance specifications are created using LNBL Windows 7.4 Software. External conditions are subject to ASHRAE NFRC100-2010 standard (US standard). 2. Information provided for guidance only and should not be treated as a substitute for detailed technical advice. Landson Glass disclaims any liability for loss or damage suffered from the use of such data. 3. U Values in the table are based on Winter climate only. 4. To the best of Landson Glass’ knowledge, all information is believed to be true and correct at time of compilation. |
||||||||||||||
